Lighting control for aquariums

TROCAL LED Control

LED CONTROLLER FOR SIMULATION OF NATURAL LIGHT CONDITIONS IN FRESHWATER AND SEAWATER AQUARIUMS.

  •  4 channel LED dimming control for up to 2 Trocal LED lights with 2 separately controllable channels.
  •  allows sunrise and sunset scenarios with color change during the day
  •  moon phase simulation
  • acclimatisation program for newly set-up aquaria
  • programming on the device or via PC (USB port)
  • buffer memory saves data in case of power outage
  • suitable for all Dennerle Trocal LEDs (fresh and sea water)

The TROCAL LED Control manages up to 2 Trocal LED lights, each of them disposing of 2 separately controllable channels. The mixing ratio of the TROCAL LEDs 2 light color channels can be adjusted individually (light colors Trocal LED: warm white and cool white; light colors Trocal LED Marinus: daylight and actinic blue). Due to the free programming of up to 8 dimming times per channel and per day the Dennerle TROCAL LED Control offers very flexible lighting options.

For easy initial use, 4 lighting programs are already pre-set, but may be modified. With 6 buttons (4 navigation buttons, confirmation and back button) the device is very easy to use. Even more comfortable is the programming of the lighting time and the color/brightness profiles by means of the PC software. The data is then easily transferred to the device via USB.

SOFTWARE-DOWNLOAD:

GHL-Control Center

A safe operation is ensured by the safety low voltage of 24 volts. As an additional feature the buffer memory saves data in case of power outage.




Content:


1x Trocal LED Control
1x Trocal LED Connect (connecting cable für TROCAL LED)


Note: For connecting a second LED TROCAL LED an additional connecting cable is required.




Art.Art.No.
Dennerle TROCAL LED Control5564
  • Technical data

    Input: 12-24 V DC

    Output / Channel (max): 2.5 A

    Controllable maximum performance/lamp: 120 W at 24 V

    Connections: USB; 4 x Mini-Power-DIN 3-pin

    Dimensions: 130mm x 84mm x 24mm
